• Adjustable Length in 7.5 mm increments
• Mounting hole distance 40mm (Centre to Centre)
• Rear kickstand, adjustable in length with a modern design which makes for easy mounting at the chain stay
• Sliding shell with F18 Kickstand Shoe
• Max Load 50 kg
• Includes stainless mounting screws
• Weight 360 g
• Fatigue test for spring mechanism for side movement
• Strut length L1 210 - 375 mm
• Suitable for 20" to 29" Wheeled Bicycles

Rear kickstand adjustable in length with a modern design which makes for easy mounting at the chain stay. It's movable with a compression spring. Suitable for almost all bikes.

Tech Specs

• ESGE Rear Kickstands


• Spring for side movement


• Dampening of the stay


• Fatigue test for spring mechanism


• Adjustable in steps of 7.5 mm


• Strut length L1 210 - 375 mm every 7.5 mm (20"-29")


• Support hole distance 40 mm


• Length adjustment by grub screw (max. 4.3 Nm)


• Weight 360 g


• Max. Load 50 kg

Material

• Aluminium die-cast GD-AlSi9Cu3


• Colour Kickstand: powder coated black


• Colour Sliding Shell: silver


• Pin hardened steel, zinc plated


• Mounting screws stainless

Supplied With:

• Mounting hardware M5x20 / M6x20 (special size on request)


• Sliding shell with F18 Kickstand Shoe
